Product Information
Management features | |
Switch type | Managed |
Switch layer | L2 |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Traffic classification | Yes |
ARP inspection | Yes |
Configuring Location Settings (CLI) | Yes |
MIB support | Y |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 4 |
Console port | RJ-45/Mini-USB |
USB 2.0 ports quantity | 1 |
Network | |
Networking standards | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u |
10G support | No |
Full duplex | Yes |
Link aggregation | Yes |
Broadcast storm control | Yes |
Auto MDI/MDI-X | Yes |
Spanning tree protocol | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
VLAN support | Yes |
Number of VLANs | 4094 |
Data transmission | |
Switching capacity | 56 Gbit/s |
Forwarding rate | 41.67 Mpps |
MAC address table | 16000 entries |
Static route | Yes |
Number of static routes | 16 |
Jumbo frames support | Yes |
Jumbo frames | 10240 |
Security | |
DHCP features | DHCP snooping |
Access Control List (ACL) | Yes |
IGMP snooping | Yes |
IGMP entries | 1024 |
SSH/SSL support | Yes |
Loop protection | Yes |
BPDU filtering/protection | Yes |
Authentication | Web-based authentication |
Authentication type | RADIUS |
Multicast features | |
Multicast support | Yes |
IPv4 multicast entries | 1024 |
IPv6 multicast entries | 1024 |
Design | |
Product colour | Grey |
LED indicators | Yes |
Performance | |
Built-in processor | Yes |
Processor model | ARM7 |
Processor frequency | 800 MHz |
Memory type | DRAM |
Internal memory | 512 MB |
Flash memory | 256 MB |
Mean time between failures (MTBF) | 2026793 h |
Power | |
AC input voltage | 110 - 240 V |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) | No |
Operational conditions | |
Operating temperature (T-T) | -5 - 50 øC |
Storage temperature (T-T) | -25 - 70 øC |
Operating relative humidity (H-H) | 5 - 90% |
Storage relative humidity (H-H) | 5 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 4500 m |
Weight & dimensions | |
Width | 444.5 mm |
Depth | 240 mm |
Height | 44 mm |
Weight | 2.63 kg |
Logistics data | |
Harmonized System (HS) code | 85176990 |
Warranty | |
Base Warranty | Non Non |
