7dbi Omni Vertical Polarized Antenna N 2.4/5/6 GHz
ITCurry #: 0918Y089 | Article #: IW-ANT-OMV-2567-N=-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The Cisco 2.4/5/6 GHz Tri-Band Omnidirectional Antenna (IW-ANT-OMV-2567-N), is especially designed to complement interior or exterior mounted wireless network systems. The integrated male N(m) connector is embedded in the antenna base cap for direct mounting to the chosen
AP. The ingress protection rating of this antenna element permits either upright or inverted orientation in outdoor locations. The antenna may also be pole-mounted when separation from the APisrequired for ptimum positioning.
The IW-ANT-OMV-2567-N is a self-identifying antenna having circuitry that enablessupported Cisco access points(APs) to self-identify the antenna. This antenna has a built-in EEPROM that the APsread to automatically configure the antenna type and the gain in the wireless controller.
| Performance | |
| Frequency band | 6 GHz |
| Antenna gain (2.4 GHz) | 4 dBi |
| Antenna gain (5 GHz) | 7 dBi |
| Impedance | 50 O |
| Bandwidth note | 5490 - 6875 MHz |
| Vertical beam width (2.4 GHz) | 37ø |
| Vertical beam width (5 GHz) | 22ø |
| Antenna gain level (max) | 7 dBi |
| Features | |
| Antenna type | Omni-directional antenna |
| Connector gender | Male |
| Polarization | Vertical polarization |
| International Protection (IP) code | IP67 |
| Power handling | 2 W |
| Purpose | Outdoor |
| Product colour | Grey |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 70 øC |
| Storage temperature (T-T) | -40 - 85 øC |
| Weight & dimensions | |
| Height | 286.8 mm |
| Weight | 137 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Manual | Yes |
| Warranty | |
| Base Warranty | Non Non |
