Product Information
KX Low-Profile Quad Monitor Arms, Column Desk Mount, White
Chief’s premium Kontour™ KX Series Monitor Arms provide the most complete range of motion available, due to our exclusive FleXlink design. KX Series mounts with FleXlink optimize the depth of dual-, triple- and quad-monitor installs for shallow depth desktops while still providing full range of motion for screen sharing with colleagues.
This series includes Chief's patented Centris™ Extreme Tilt technology for effortless fingertip monitor positioning. Kontour™ monitor mounts float your displays in the optimal ergonomic position above your work surface to create a more productive and comfortable work environment.
Mounting | |
Minimum screen size | 25.4 cm (10") |
Maximum weight capacity | 36.3 kg |
Maximum weight capacity (per display) | 11.3 kg |
Maximum screen size | 76.2 cm (30") |
Mounting | Clamp |
Minimum VESA mount | 75 x 75 mm |
Maximum VESA mount | 100 x 100 mm |
Panel mounting interface | 75 x 75,100 x 100 mm |
Number of displays supported | 4 |
Extension arm (max) | 54.1 cm |
Desk thickness (min) | 1.28 cm |
Desk thickness (max) | 6.38 cm |
Mounting type | Desk |
Ergonomics | |
Height adjustment | Yes |
Height adjustment type | Manual |
Height adjustment range | 0 - 165.1 mm |
Adjustable depth | Yes |
Tilt angle range | -10 - 75ø |
Angle of rotation | 180ø |
Turn angle | 90ø |
Number of arms | 4 |
Cable management | Yes |
Tilt adjustment | Yes |
Design | |
Product colour | White |
Orientation | Landscape/Portrait |
Packaging data | |
Quantity per pack | 1 pc(s) |
Logistics data | |
Harmonized System (HS) code | 85299097 |
Warranty | |
Base Warranty | Non Non |
