HDMI to VGA Active Video Adapter Cable - 1080p 2m
ITCurry #: 1842A081 | Article #: C2G41472-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
This HDMI to VGA Active Video Adapter Cable is an easy and convenient solution for connecting a VGA display to an HDMI equipped computer in your home or your office. This adapter cable converts an active digital HDMI signal to an analog VGA video signal, supports up to a 1080p resolution, and meets the requirements of high performance applications - perfect for Chromebooks, laptops, and desktops with HDMI outputs.
Avoid frustration by simply plugging the adapter cable into your computer's HDMI output, then attach to the VGA input of your monitor or projector. The cable form factor of this adapter provides a simple and convenient solution that eliminates the need for a separate adapter and cable. The added USB power cable is perfect for those times when additional connectivity power is needed.
| Features | |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Connector contacts plating | Nickel |
| Cable length | 1.8 m |
| Connector 1 | VGA (D-Sub) |
| Connector 2 | HDMI |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Maximum resolution | 1920 x 1080 pixels |
| Data transfer rate | 1.65 Gbit/s |
| Bandwidth | 165 MHz |
| Maximum refresh rate | 60 Hz |
| Product colour | Black |
| Chipset | AG6200: QFN-48 pin |
| Jacket material | Polyvinyl chloride (PVC) |
| AWG wire size | 28/30 |
| Converter type | Active video converter |
| Certification | CE, 2011/65/EU ROHS 2 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 øC |
| Storage temperature (T-T) | -10 - 80 øC |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Cable diameter | 3 mm |
| Weight | 80 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Warranty | |
| Base Warranty | Non Non |
