Rugged and Powerful
The XM7-40 is a rugged and industrial 4-inch (112mm) premium level Auto-ID Mobile Liner and Linerless Label printer bursting with value added design features and software add-ons. Providing premium-level performance at speeds of up to 5ips at 203dpi producing high quality printing output. The XM7-40 features a rugged, compact design, embedded Peeler, TFT Colour Display, drop protection of 2.1 metres and an IP54-rating. With a smart battery with universal USB Type-C Power delivery charging, this mobile label printer provides a wealth of battery health information through BIXOLON’s web-based printer profile management software XPM™, guaranteeing consistent performance throughout prolonged operations.
Providing seamless connectivity, the XM7-40 presents USB 2-0 and Serial interfaces as standard, with optional Bluetooth V5.0 Classic (MFi Certification) and WLAN 802.11a/b/g/n wireless technology which can be connected simultaneously. Supporting easy Bluetooth pairing via NFC allowing compatibility with major operations including Android™, iOS™ and Windows™. The printer also boasts unity with market leading command languages such as SLCS, BPL-Z™, BPL-C™ and BXL/POS to allow for seamless integration with customers’ existing systems.
Boasting a 128 MB SRAM, 256 MB Flash memory as standard and optional 256 MB SDRAM, 512 MB Flash memory enabling the storage of fonts and graphics, alongside firmware upgrades and tools. The XM7-40 prints directly from SAP® Smart Forms and is compatible with a range of label editing applications including BIXOLON’s Label Artist™, Label Artist Mobile™ for iOS™ & Android™, alongside the industry leading Bartender® software.
| Printing | |
| Maximum resolution | 203 x 203 DPI |
| Printable dot numbers | 8 dot |
| Print speed | 5 ips |
| Print speed | 127 mm/sec |
| Character sets | 16 BPL-Z, SLCS |
| Print technology | Direct thermal |
| Type | Mobile printer |
| Paper handling | |
| Maximum roll diameter | 6.6 cm |
| Supported paper width | 50 - 112 mm |
| Maximum printing width | 10.4 cm |
| Media thickness | 0.07 ñ 0.15 mm |
| Ports & interfaces | |
| USB port | Yes |
| USB connector | USB Type-C |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Connectivity technology | Wired & Wireless |
| Network | |
| Ethernet LAN | No |
| Wi-Fi | No |
| Features | |
| Built-in barcodes | 1D, 2D, AZTECCODE, CODABAR (NW-7), Codablock, Code 11, Code 39, Code 49, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, GS1 DataBar, IMB, Industrial 2/5, Interleaved 2/5, Logmars, MSI, MaxiCode, MicroPDF417, PDF417, POSTNET, Plessey, QR Code, Standard 2/5, TLC39, UPC-A, UPC-E |
| Page description languages | CPCL-native, ZPL II |
| Internal memory | 128 MB |
| Storage media | Flash |
| Flash memory | 256 MB |
| Design | |
| Product colour | Black |
| Built-in display | Yes |
| Display | LCD |
| Colour display | No |
| Display resolution | 240 x 320 pixels |
| Power | |
| Power source type | Battery |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery voltage | 7.2 V |
| Battery capacity | 6800 mAh |
| Operational conditions | |
| Operating temperature (T-T) | -15 - 50 øC |
| Storage temperature (T-T) | -30 - 70 øC |
| Operating relative humidity (H-H) | 10 - 80% |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac compatibility | Yes |
| Mobile operating systems supported | Android, iOS |
| Linux operating systems supported | Yes |
| Weight & dimensions | |
| Width | 158 mm |
| Depth | 186 mm |
| Height | 82 mm |
| Weight | 1.09 kg |
| Packaging content | |
| Drivers included | Yes |
| Logistics data | |
| Harmonized System (HS) code | 84433210 |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Other features | |
| International Protection (IP) code | IP54 |
| Warranty | |
| Base Warranty | Non Non |
