A1610-b Network Door Controller
ITCurry #: 13836287 | Article #: 02654-001Flash Sale
Less than 5 units remaining
Less than 10 units remaining
Less than 20 units remaining
More than 20 units are available
{{new Date(new Date(parseInt((dataContainer.PromoDetail.EndDate).split('(')[1].split(')')[0])) - new Date()).getDate()}} days remaining
{{new Date(new Date(parseInt((dataContainer.PromoDetail.EndDate).split('(')[1].split(')')[0])) - new Date()).getDate()}} day remaining
Price:
603.67
Inc VAT
Ex VAT
Shipping:
Out of Stock. Contact Us!
Key Specifications
-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Inc VAT
Ex VAT
Out of Stock. Contact Us!
Inc VAT
Ex VAT
Out of Stock. Contact Us!
Related products
Product Information
This barebone door controller includes everything needed to control two doors – all powered by one PoE cable. Sold without a top cover, it offers easy installation. Thanks to intelligence on the edge, it can internally handle all tasks related to door access – even if the network is down. This scalable product is fully integrated within Axis and partner solutions and suitable for both small and large installations. It includes six auxiliary I/Os for easy integration. Plus, it supports flexible authentication using different types of credentials. Furthermore, built-in cybersecurity features prevent unauthorized access and safeguard your system.
| Technical details | |
| Case design | Bare |
| Maximum number of doors | 2 door(s) |
| Built-in UPS | No |
| Interface | RJ-45 / RS-485 |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSd, HTTP/2, TLSd, QoS Layer 3 DiffServ, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, NTCIP, SIP, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf) |
| Relay inputs | 2 |
| Performance | |
| Internal storage capacity | 2 GB |
| Storage media | Flash |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wiegand interface | Yes |
| Number of Wiegand readers supported | 2 |
| Certification | EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835 |
| Power | |
| DC voltage range | 10.5 - 28 V |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-485 ports | 1 |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 55 øC |
| Storage temperature (T-T) | -40 - 55 øC |
| Operating relative humidity (H-H) | 20 - 85% |
| Weight & dimensions | |
| Width | 175 mm |
| Depth | 175 mm |
| Height | 50 mm |
| Weight | 800 g |
| Warranty | |
| Base Warranty | Non Non |
