Avh-6520 65in 4k Glass LED Interactive Display
ITCurry #: W0722124 | Article #: AVH-6520-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The Avocor H Series redefines interactive displays for modern workspaces, emphasizing seamless collaboration and connectivity. With its ultra-thin bezel and sophisticated design, it integrates effortlessly into professional environments, enhancing aesthetic appeal and functional utility. This sleek design, devoid of visible buttons or inputs, maintains a sophisticated and uncluttered profile, perfectly complementing the aesthetic standards of today's workspaces. Across all models (65", 75", and 86"), the H Series boasts a high-resolution 4K display, bringing life to content with unparalleled clarity.
The Avocor H Series has a premium feel that will enhance any meeting room, and the technology needed to accommodate high collaboration in hybrid workspaces.
Ensure every in-person and remote interaction provides a natural and intuitive meeting experience with the Avocor H Series, the perfect solution for organizations that demand both a luxury aesthetic and a high performing functional workspace.
In the hybrid work era, the H Series excels in corporate settings with its sleek design and advanced touch technology, enhancing collaboration among remote and in-office teams. Its easy installation and FUSE-powered remote management streamline IT operations, while diverse connectivity options ensure seamless device integration. The addition of Montage and Rise Vision transforms idle screens into dynamic communication hubs, keeping all team members engaged and informed, thus embodying a versatile solution for modern corporate challenges.
| Display | |
| Display diagonal | 165.1 cm (65") |
| Display brightness | 400 cd/mý |
| Display number of colours | 1.07 billion colours |
| Display resolution | 3840 x 2160 pixels |
| Anti-glare screen | Yes |
| HD type | 4K Ultra HD |
| Panel type | LCD |
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Native aspect ratio | 16:9 |
| Contrast ratio (typical) | 5000:1 |
| Response time | 6.5 ms |
| Maximum refresh rate | 60 Hz |
| Touchscreen | Yes |
| Touch technology | Multi-touch |
| Touchscreen type | Capacitive |
| Number of simultaneous touchpoints | 40 |
| Viewing angle, horizontal | 178ø |
| Viewing angle, vertical | 178ø |
| Screen glass thickness | 2 mm |
| Pen & touch differentiation | Yes |
| Palm erase | No |
| Palm rejection | No |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speaker power | 16 W |
| Built-in microphone | No |
| Network | |
| Wi-Fi | Yes |
| Antenna type | 1x1 |
| Ethernet LAN | Yes |
| Wake-on-LAN ready | Yes |
| Ports & interfaces | |
| HDCP | Yes |
| HDCP version | 2.3 |
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| USB 2.0 Type-A hub ports quantity | 2 |
| USB 2.0 Type-B Touch ports quantity | 3 |
| HDMI ports quantity | 4 |
| USB Type-C ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| HDMI version | 2.0 |
| HDMI output ports quantity | 1 |
| USB Power Delivery | Yes |
| USB Power Delivery up to | 100 W |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Line-out | Yes |
| OPS slot | 1 |
| S/PDIF out port | Yes |
| Audio output | 1 |
| RS-232 ports | 1 |
| Ergonomics | |
| Product colour | Brushed steel |
| VESA mounting | Yes |
| Panel mounting interface | 400 x 400 mm |
| Wall mountable | Yes |
| Fanless | Yes |
| Performance | |
| Ambient light sensor | Yes |
| Proximity sensor | Yes |
| Power | |
| Power consumption (max) | 227 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 11 |
| Mac compatibility | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage temperature (T-T) | 20 - 85 øC |
| Weight & dimensions | |
| Width | 1493 mm |
| Depth | 80 mm |
| Height | 877 mm |
| Weight | 37 kg |
| Packaging data | |
| Package width | 1612 mm |
| Package depth | 220 mm |
| Package height | 1034 mm |
| Package weight | 49 kg |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Cables included | HDMI, USB Type-A to USB Type-B, USB Type-C to USB Type-C |
| Remote control included | Yes |
| Batteries included | Yes |
| Mounting brackets included | Yes |
| Quick start guide | Yes |
| Stylus included | Yes |
| Stylus pen type | Passive |
| Number of stylus pens | 2 |
| Logistics data | |
| Warranty period | 3 year(s) |
| Country of origin | China |
| Warranty | |
| Base Warranty | Non Non |
