LCD Console 17.3in Widescreen DVI/hdmi Full Hd
ITCurry #: 90313512 | Article #: CL6700MW-ATA-XG-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The CL6700MW DVI Full HD LCD Console is a single rail KVM console featuring a 17.3’’ high-definition widescreen with an integrated keyboard and touchpad in a 1U rack-mountable sliding housing. The CL6700MW’s console provides front end access to compatible KVM switches utilizing space with a module that closes fl at and slides into the rack. The single rail design allows the LCD monitor, keyboard and touchpad to operate independently of each other. Multiple video ports allow the console to connect one of three types of video sources: VGA, DVI, or HDMI - for the console and CPU connection. For added convenience, the full HD console provides two HDMI ports that allow for connecting a high-defi nition monitor to the console port, and/or an HDMI compatible switch to the KVM port.
The CL6700MW features a port for an external USB mouse on the unit’s front panel, while ports for the second KVM console (keyboard, mouse and DVI, HDMI or VGA monitor) are provided on the rear panel. Server rooms already installed with compatible DVI KVM switches will have the advantage of easy access, an additional console, and a built-in space saving sliding module, without having to purchase a KVM switch.The CL6700MW includes two mini stereo ports for connecting audio speakers.
| Warranty | |
| Base Warranty | Non Non |
| Ports & interfaces | |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-D |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Audio connections | Y |
| Headphone outputs | 2 |
| Console port | RJ-11 |
| Performance | |
| Maximum resolution | 1920 x 1080 pixels |
| Design | |
| Rack mounting | Y |
| Rack capacity | 1U |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Certification | US 7505255 , CN ZL 200610081929.7 , TW I340311 |
| Display | |
| Built-in display | Y |
| Display | LCD |
| Display diagonal | 43.9 cm (17.3") |
| Power | |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 19.4 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 480 mm |
| Depth | 589.2 mm |
| Height | 44 mm |
| Weight | 11.4 kg |
| Packaging content | |
| Cables included | AC, KVM |
| Manual | Y |
| Technical details | |
| Sustainability certificates | RoHS |
