2x2 4k Hdmi Matrix Switch Up To 15m
ITCurry #: 90313729 | Article #: VM0202H-AT-G
slide 2 of 3
Price:
172.83
Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Related products
slide 6 to 10 of 15
Product Information
The VM0202H is a 2 X 2 HDMI Matrix Switch that meets HDMI Specification features including 3D, Deep Color up to 12- bit, and data rates up to 10.2 Gbps. Engineered for the future trend of high-definition video switching, the VM0202H supports computer and video signals at resolutions up to 4K.
1x VM0202H 2x2 4K HDMI Matrix Switch
1x Rack Mount Kit
1x 0AD6-1006-26EG Power Adapter
1x 2XRT-0106G IR Remote Control
1x 2XRT-0003G IR Receiver
1x User Instructions
| Features | |
| Product type | AV matrix switcher |
| Data transfer rate | 10.2 Gbit/s |
| Maximum pixel clock | 340 MHz |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| HDCP version | 1.4 |
| 3D | Yes |
| Firmware upgradeable | Yes |
| Extended display identification data (EDID) | Yes |
| Supported resolutions | 4096 x 2160, 3840 x 2160 |
| Design | |
| Housing colour | Black |
| Housing material | Metal |
| Rack mounting | Yes |
| Control type | Buttons |
| LED indicators | Yes |
| Remote control included | Yes |
| Display | |
| Built-in display | No |
| Ports & interfaces | |
| HDMI input ports quantity | 2 |
| HDMI output ports quantity | 2 |
| USB connector type | Micro-USB |
| USB ports quantity | 1 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
| Power | |
| Power consumption (typical) | 4.3 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Logistics data | |
| Products per master (outer) case | 5 pc(s) |
| Master (outer) case gross weight | 5.33 kg |
| Master (outer) case length | 325 mm |
| Master (outer) case width | 250 mm |
| Master (outer) case height | 175 mm |
| Master (outer) case net weight | 4.2 kg |
| Harmonized System (HS) code | 85299097 |
| Weight & dimensions | |
| Width | 200 mm |
| Depth | 76 mm |
| Height | 42 mm |
| Weight | 840 g |
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 980 g |
| Packaging content | |
| Rack mount kit | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| IR receiver included | Yes |
| Warranty | |
| Base Warranty | Non Non |
