| Output |
| Output Power Capacity |
2700 Watts / 3000 VA |
| Max Configurable Power |
2700 Watts / 3000 VA |
| Nominal Output Voltage |
230V |
| Output Voltage Distortion |
Less than 5% at full load |
| Output Frequency (sync to
mains) |
47 - 63 Hz |
| Other Output Voltages |
208,220,240 V |
| Crest Factor |
3 : 1 |
| Waveform Type |
Sine wave |
| Output Connections |
8 x IEC 320 C13
1 x IEC 320 C19
2 x IEC Jumpers |
| Input |
| Nominal Input Voltage |
230V |
| Input Frequency |
47 - 63 Hz |
| Input Connections |
IEC-320 C20
Schuko CEE 7 / EU1-16P
British BS1363A |
| Input voltage range for main
operations |
141 - 255,160 - 280V |
| Other Input Voltages |
208,220,240 V |
| Transfer Time |
2-4 ms |
| Cord Length |
1.83 meters |
| Batteries &
Runtime |
| Battery Type |
Maintenance-free sealed
Lead-Acid battery with suspended electrolyte : leakproof |
| Typical recharge time |
3 hour(s) |
| Replacement Battery |
APCRBC117 |
| Communications &
Management |
| Interface Port(s) |
SmartSlot |
| Available SmartSlot Interface
Quantity |
1 |
| Control panel |
LED status display with On
Line : On Battery : Replace Battery and Overload indicators,Multi-function
LCD status and control console |
| Emergency Power Off (EPO) |
Yes |
| Audible Alarm |
Alarm when on battery :
distinctive low battery alarm : configurable delays |
| Surge Protection
and Filtering |
| Surge energy rating |
645 Joules |
| Filtering |
Full time multi-pole noise
filtering : 0.3% IEEE surge let-through : zero clamping response time :
meets UL 1449 |
| Physical |
| Height |
85.00 mm |
| Width |
432.00 mm |
| Depth |
667.00 mm |
| Rack Height |
2U |
| Color |
Black |
| Environmental |
| Operating Environment |
0 - 40 øC |
| Operating Relative Humidity
|
0 - 95% |
| Operating Elevation |
0-3000 meters |
| Storage Temperature |
-15 - 45 øC |
| Storage Relative Humidity |
0 - 95% |
| Storage Elevation |
0-15000 meters |
| Audible noise at 1 meter from
surface of unit |
55.00 dBA |
| Online Thermal Dissipation
|
184.00 BTU/hr |
| Conformance |
| Regulatory Approvals |
C-tick,CE,EN 50091-1,EN
50091-2,EN 60950,FCC Part 15 Class A,GOST,IRAM,UL 1778,VDE |
| Environmental Compliance |
RoHS 7b Exemption,REACH:
Contains No SVHCs
|
