Output |
Output Power Capacity |
4200 Watts / 6000 VA |
Max Configurable Power |
4200 Watts / 6000 VA |
Nominal Output Voltage |
230 V (Configurable for 220 :
230 or 240 nominal output voltage) |
Efficiency at Full Load |
92.0% |
Output Voltage Distortion |
Less than 3% |
Waveform Type |
Sine wave |
Other Output Voltages |
220,240 V |
Crest Factor |
3 : 1 |
Output Frequency (sync to
mains) |
50/60 Hz +/- 3 Hz user
adjustable +/- 0.1 |
Output Connections |
8 x IEC 320 C13
2 x IEC 320 C19
4 x IEC Jumpers |
Bypass |
Internal Bypass (Automatic and
Manual) |
Input |
Nominal Input Voltage |
230 V |
Input Frequency |
50/60 Hz +/- 5 Hz (auto
sensing) |
Input Connections |
Hard Wire 3-wire |
Input voltage range for main
operations |
160 - 280 V |
Input voltage adjustable range
for mains operation |
100 - 280 V |
Other Input Voltages |
220,240 V |
Batteries &
Runtime |
Battery Type |
Maintenance-free sealed
Lead-Acid battery with suspended electrolyte : leakproof |
Typical recharge time |
2.50 hour(s) |
Replacement Battery |
RBC44 |
Communications &
Management |
Interface Port(s) |
DB-9 RS-232,RJ-45 10/100 Base-T,Smart-Slot |
Pre-Installed SmartSlot Cards |
AP9631 |
Control panel |
LED status display with load
and battery bar-graphs and On Line : On Battery : Replace Battery :
Overload and Bypass Indicators |
Audible Alarm |
Alarm when on battery :
distinctive low battery alarm : overload continuous tone alarm |
Emergency Power Off (EPO) |
Yes |
Surge Protection
and Filtering |
Surge energy rating |
480 Joules |
Filtering |
Full time multi-pole noise
filtering : 0.3% IEEE surge let-through : zero clamping response time :
meets UL 1449 |
Physical |
Height |
432.00 mm |
Width |
130.00 mm |
Depth |
660.00 mm |
Weight |
54.55 kg |
Rack Height |
3 U |
Color |
Black |
Environmental |
Operating Environment |
0 - 40 øC |
Operating Relative Humidity
|
0 - 95% |
Operating Elevation |
0-3000 meters |
Storage Temperature |
-15 - 45 øC |
Storage Relative Humidity |
0 - 95% |
Storage Elevation |
0-15000 meters |
Audible noise at 1 meter from
surface of unit |
55.00 dBA |
Online Thermal Dissipation |
1221.00 BTU/hr |
Conformance |
Regulatory Approvals |
C-tick,CE,CSA,EN 50091-1,EN
50091-2,EN 55022 Class A,EN 60950,EN 61000-3-2,GOST,UL Listed,VDE |
Environmental Compliance |
RoHS 7b Exemption,China
RoHS,REACH: Contains No SVHCs,Contains Lithium Battery |
