Mini Pc Ace Plus De3650-c
ITCurry #: 91513002 | Article #: 91.DER00.E5A0-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Intel® Celeron® Processor J6412, Fanless design with remote management UHD (4K) media player.
UHD (4k) content playback
DE3650 is capable of driving 2x UHD (4k) content. With a resolution that goes up to 3840x2160 pixels your content will be close to perfect. This feature makes the players that are capable of delivering content that is fluent and stutter free in UHD (4k).
-20degC operating temperature
AOPEN has good experience in mechanism and electronic design. It has designed a good body temperature control for DE3650. The equipment can operate normally even at a low temperature of minus 20 degrees C. It is suitable for industrial or outdoor applications that require low temperatures.
Fanless design
With fanless design, the device is passively cooling and is dustproof. Therefore, it's very suitable for segments such as industry.
Small form factor
This form factor ensures an easy integration into kiosks or behind screens. The AOPEN small form factor is a standard that is used for Digital Engine (DE) models. The size of DE3650 is 166x35x110 mm. the mount hole of bracket just same as DE series
Trusted Platform Module 2.0
The TPM is a dedicated micro controller, designed to secure hardware through integrated cryptographic keys. This means the data on your hard drive will be encrypted to ensure your data is safe, even when your device gets stolen.
AOPEN intelligent Control
AOPEN Intelligent Control (AiCU) is built for global enterprise brands, AiCU enables network operators with an intelligent device management solution that automates industrial and commercial applications. AiCU brings cloud service and advanced embedded device control technology together into a single dashboard.
Support AOPEN AiCU Out-of-Band (OOB) remote management (optional)
The AiCU Out-of-Band (OOB) Endpoint Management Solution provides a hardware-based comprehensive device management tool that is not dependant on host Operating System functionality. AiCU OOB lowers your Total Cost of Ownership by reducing on-site maintenance and allowing full software patch and update control.
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel© Celeron© |
| Processor model | N6210 |
| Processor frequency | 1.2 GHz |
| Memory | |
| Internal memory | 4 GB |
| Maximum internal memory | 20 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 1 x 4 GB |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 2666 MHz |
| Storage | |
| Total storage capacity | 64 GB |
| Storage media | eMMC |
| Optical drive type | No |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel© UHD Graphics |
| On-board graphics card model | Intel© UHD Graphics |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | No |
| Ports & interfaces | |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Mini DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 3 |
| Combo headphone/mic port | Yes |
| DC-in jack | Yes |
| Design | |
| Chassis type | Mini PC |
| Volume | 0.68 L |
| Product colour | Black |
| Performance | |
| Market positioning | Business |
| Audio chip | Realtek ALC897 |
| Trusted Platform Module (TPM) | Yes |
| Product type | Mini PC |
| Software | |
| Operating system installed | No |
| Power | |
| Power supply | 40 W |
| Power supply input voltage | 100 - 240 V |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 40 øC |
| Storage temperature (T-T) | -30 - 60 øC |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
| Width | 166 mm |
| Depth | 110 mm |
| Height | 35 mm |
| Weight | 610 g |
| Warranty | |
| Base Warranty | Non Non |
| Packaging content | |
| Display included | No |
| Other features | |
| Warranty period | 2 year(s) |
