Large Format Monitor - Qm5502 - 55in - 3480x2160 (uhd 4k)
ITCurry #: 92942517 | Article #: QM5502
Related products
Product Information
The QM-5502 55” 4K digital signage display is designed for digital signage applications that require crisper and clearer image presentation. Featuring a premium IPS panel for 24/7 operation, 4K UHD resolution with a wide viewing angle, and easy-to-use media playback via a USB drive, the QM-5502 digital signage display is ideally used for retail stores, corporate meeting areas, hotels and other public spaces.
EXPERIENCE THE 4K DIFFERENCE
Don’t miss a single detail with the powerful 4K digital signage display. View smooth 4K video and images to the new level of detail and clarity. Offering 8.3 million pixels, the QM-5502 provides the ultimate 4K digital signage experience, delivering business messaging, and boost customer engagement.
SIMPLE CONTENT PLAYBACK AND SCHEDULING
The embedded media player allows users to conveniently play content from a USB drive.
Simply create scheduled playlists based on time and day and configure playback settings with the included remote control to display your personalised content.
LANDSCAPE/PORTRAIT CAPABILITY
The commercial-grade signage-friendly and can perfectly fit either in a landscape or in a portrait mode to experience complete screen orientation flexibility and fulfill the need in different scenarios.
PATENTED ANTI-BURN-IN™ TECHNOLOGY
To combat the effects of traditional LCD burn-in or ghosting, AG Neovo utilises its patented Anti-Burn-in™ Technology to prevent image burn-in and assure the extended life span for displays.
FREE PID COMMAND & CTRL SOFTWARE
PID Command & Ctrl provides intuitive user interfaces for remote management via laptops and mobile devices and offers easy creation on video wall displays. The software also has simple colour calibration, temperature check, IR/key locking options, and time on usage monitoring for daily maintenance.
| Display | |
| Panel type | IPS |
| Display diagonal | 138.7 cm (54.6") |
| Display technology | LED |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 400 cd/mý |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Response time | 5 ms |
| Contrast ratio (typical) | 5000:1 |
| Viewing angle, horizontal | 178ø |
| Viewing angle, vertical | 178ø |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.315 x 0.315 mm |
| Horizontal scan range | 15 - 136 kHz |
| Vertical scan range | 23 - 76 Hz |
| Haze rate | 3% |
| Surface hardness | 2H |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 3 |
| DVI port | No |
| VGA (D-Sub) input ports | 1 |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
| RS-232 interface | Yes |
| Remote (IR) output | 1 |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 400 x 400 mm |
| Anti-glare screen | Yes |
| Performance | |
| Purpose | Commercial |
| Operating hours (hours/days) | 24/7 |
| Power | |
| Power consumption (typical) | 135 W |
| Power consumption (standby) | 0.5 W |
| Input voltage | 100 - 240 V |
| Power consumption (off) | 0.3 W |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Display width | 1241.8 mm |
| Display depth | 63.6 mm |
| Display height | 712.6 mm |
| Display weight | 17.2 kg |
| Packaging data | |
| Package width | 1350 mm |
| Package depth | 160 mm |
| Package height | 860 mm |
| Package weight | 21.4 kg |
| Packaging content | |
| Remote control included | Yes |
| Remote control type | IR |
| Batteries included | Yes |
| Cables included | AC, HDMI |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 øC |
| Storage relative humidity (H-H) | 10 - 90% |
| Technical details | |
| USB playback | Yes |
| Sustainability compliance | Yes |
| Compliance certificates | BSMI, EAC, Federal Communications Commission (FCC), Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE |
| Other features | |
| Quick start guide | Yes |
| Audio input | 3.5mm |
| Audio output | 1 x RCA |
| Cable lock slot | Yes |
| RS-232 input ports | 1 |
| Cable lock slot type | Kensington |
| Power supply type | Internal |
| Warranty | |
| Base Warranty | Non Non |
