Patch panel CAT6a Shielded 24-port 0.5u (dn91624sslea)
ITCurry #: M9233816 | Article #: DN-91624S-SL-EA-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Very space-saving (only 0.5U) - With dust protection caps - Future-oriented standards and high-end quality for your network
- Slim installation height of only 0.5 U
- Up to 48 ports per U possible (2 x 24 port panels)
- Dust protection flaps on the RJ45 sockets
- 360° shield contacting
- Cable clamp for fixing and routing, reclosable
- Quick-release fastener to secure the housing cover
The DIGITUS® 24-port patch panel offers a very high packing density with only 0.5 U. This means that up to 48 ports can be implemented on 1 U with two 0.5 U panels. The patch panel is shielded and equipped with dust protection caps on the RJ45 sockets. The 360° shield contact of the cables ensures the best performance characteristics. The installation cables can be securely fixed with the integrated cable clamps. The quick-release fastener on the housing ensures easy and tool-free access to the LSA insulation displacement connectors.
| Network | |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Ports quantity | 24 |
| Connector(s) | RJ-45 |
| Cable types supported | Cat6a |
| Design | |
| Product colour | Black |
| Material | SECC |
| Mounting | Rack mounting |
| Rack capacity | 0.5U |
| Certificates | |
| Certification | EN1.4301, UNS S30400, AISI 304, LMSAD110 |
| Packaging data | |
| Package width | 140 mm |
| Package depth | 530 mm |
| Package weight | 1.5 kg |
| Package volume | 2597 cmü |
| Logistics data | |
| UK Trade Tariff code | 85369010 |
| Country of origin | China |
| Harmonized System (HS) code | 85371098 |
| Warranty | |
| Base Warranty | Non Non |
