Product Information
Features
Automatic Self Test, Automatic Voltage Regulation (AVR), Built-in SmartSlot, Hot Swap Batteries, Intelligent Battery Management, Line-interactive, Load Meter, Network-grade line conditioning, Overload Indicator, Replace Batt Indicator, Scalable Run Time, Sine-wave output, Software, Status Indicator LED's, USB Connectivity, User Replaceable batteries, Wide input voltage range
 Includes
CD with software, Smart UPS signalling RS-232 cable, USB cable, User Manual
| Features | |
| Output power capacity | 1 kVA |
| Output power | 800 W |
| Surge energy rating | 320 J |
| Emergency Power Off (EPO) | Yes |
| Battery | |
| Typical backup time at full load | 9.7 min |
| Typical backup time at half load | 33.9 min |
| Replacement battery cartridge | APC Replacement Battery RBC7 |
| Design | |
| Product colour | Black |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -15 - 45 øC |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Packaging data | |
| Bundled software | - PowerChute Business Edition v6.2.2 Agent for Linux - PowerChute Business Edition v6.2.2 for Netware 5.1/6.0 - PowerChute Business Edition v6.2.2 for XP / 2000 / NT(Sp6 or higher) - 5 Node - PowerChute Business Editon v6.0.2 for Solaris 8.0 |
| Logistics data | |
| Products per pallet | 24 pc(s) |
| Other features | |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
| Interface | DB-9 RS-232, SmartSlot, USB |
| Output connections | (8)IEC 320 C13 (2)IEC Jumpers |
| Input connection type | IEC-320 C14 |
| Dimensions (WxDxH) | 170.2 x 439.4 x 215.9 mm |
| Nominal output voltage | 230 V |
| Output voltage note | Configurable for 220: 230 or 240 nominal output voltage |
| Filtering description | 0.3% IEEE/UL 1449 |
| Nominal input voltage | 230 V |
