| Output |
| Output Power Capacity |
1400 Watts / 2000 VA |
| Max Configurable Power |
1400 Watts / 2000 VA |
| Nominal Output Voltage |
230V |
| Output Voltage Note |
Configurable for 220 : 230 or
240 nominal output voltage |
| Efficiency at Full Load |
90.0% |
| Output Voltage Distortion |
Less than 3% |
| Output Frequency (sync to
mains) |
50/60 Hz +/- 3 Hz user
adjustable +/- 0.1 |
| Other Output Voltages |
220,240 |
| Crest Factor |
3 : 1 |
| Waveform Type |
Sine wave |
| Output Connections |
6 x IEC 320 C13
2 x IEC Jumpers |
| Bypass |
Built-in Bypass |
| Input |
| Nominal Input Voltage |
230V |
| Input Frequency |
50/60 Hz +/- 5 Hz (auto
sensing) |
| Input Connections |
IEC-320 C20
Schuko CEE 7 / EU1-16P
British BS1363A |
| Cord Length |
2.44 meters |
| Input voltage range for main
operations |
160 - 280V |
| Input voltage adjustable range
for mains operation |
100 - 280V |
| Other Input Voltages |
220,240 V |
| Batteries &
Runtime |
| Battery Type |
Maintenance-free sealed
Lead-Acid battery with suspended electrolyte : leakproof |
| Typical recharge time |
4 hour |
| Replacement Battery |
RBC31 |
| Communications &
Management |
| Interface Port(s) |
DB-9 RS-232,SmartSlot |
| Available SmartSlot Interface
|
1 |
| Control panel |
LED status display with load
and battery bar-graphs and On Line : On Battery : Replace Battery :
Overload and Bypass Indicators |
| Audible Alarm |
Alarm when on battery :
distinctive low battery alarm : overload continuous tone alarm |
| Surge Protection
and Filtering |
| Surge energy rating |
420 Joules |
| Filtering |
Full time multi-pole noise
filtering : 0.3% IEEE surge let-through : zero clamping response time :
meets UL 1449 |
| Physical |
| Height |
432.00 mm |
| Width |
85.00 mm |
| Depth |
483.00 mm |
| Rack Height |
2U |
| Color |
Black |
| Environmental |
| Operating Environment |
0 - 40 øC |
| Operating Relative Humidity
|
0 - 95% |
| Operating Elevation |
0-3000 meters |
| Storage Temperature |
-20 - 50 øC |
| Storage Relative Humidity |
0 - 95% |
| Storage Elevation |
0-15000 meters |
| Audible noise at 1 meter from
surface of unit |
50.00 dBA |
| Online Thermal Dissipation
|
543.00 BTU/hr |
| Conformance |
| Regulatory Approvals |
C-tick,CE,EN 50091-1,EN
50091-2,EN 55022 Class A,EN 60950,EN 61000-3-2,GOST,VDE |
| Environmental Compliance |
RoHS 7b Exemption,China RoHS
|
